Sharp UX-P115 User Manual

UX-P115U
8
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
15 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C109]
16 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C110]
17 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C111]
18 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C112]
19 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C113]
20 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C114]
21 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C115]
22 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C116]
23 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C117]
24 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C118]
25 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C119]
26 VCKYCY1HB103K AA C Capacitor(50WV 0.01µ F) [C120]
27 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C121]
28 VCCCCY1HH330J AA C Capacitor(50WV 33PF) [C122]
29 VCCCCY1HH150J AB C Capacitor(50WV 15PF) [C123]
30 VCKYCY1HB103K AA C Capacitor(50WV 0.01µ F) [C126]
31 VCKYCY1HB472K AA C Capacitor(50WV 4700PF) [C127]
32 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C128]
33 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C129]
34 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C130]
35 VCKYCY1AF105Z AC C Capacitor(10WV 1µ F) [C131]
36 VCKYCY1AF105Z AC C Capacitor(10WV 1µ F) [C132]
37 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C133]
38 VCKYCY1AF105Z AC C Capacitor(10WV 1µ F) [C134]
39 VCKYCY1AF105Z AC C Capacitor(10WV 1µ F) [C135]
40 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C136]
41 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C137]
42 VCKYCY1AF105Z AC C Capacitor(10WV 1µ F) [C139]
43 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C140]
44 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C141]
45 VCKYCY1AF105Z AC C Capacitor(10WV 1µ F) [C142]
46 VCKYCY1AF105Z AC C Capacitor(10WV 1µ F) [C143]
47 VCKYCY1AF105Z AC C Capacitor(10WV 1µ F) [C144]
48 VCKYCY1AF105Z AC C Capacitor(10WV 1µ F) [C145]
49 VCKYCY1AF105Z AC C Capacitor(10WV 1µ F) [C146]
50 VCKYCY1AF105Z AC C Capacitor(10WV 1µ F) [C147]
51 VCCCCY1HH220J AA C Capacitor(50WV 22PF) [C148]
52 VCCCCY1HH220J AA C Capacitor(50WV 22PF) [C149]
53 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C154]
54 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C155]
55 VCKYCY1AB105K AB C Capacitor(10WV 1µ F) [C157]
56 VCKYCY1AB105K AB C Capacitor(10WV 1µ F) [C159]
57 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C160]
58 VCKYCY1AF105Z AC C Capacitor(10WV 1µ F) [C161]
59 VCKYCY1AF105Z AC C Capacitor(10WV 1µ F) [C162]
60 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C163]
61 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C167]
62 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C168]
63 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C169]
64 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C171]
65 VCKYCY1CB104K AB C Capacitor(16WV 0.1µ F) [C172]
66 VCKYCY1AB105K AB C Capacitor(10WV 1µ F) [C175]
67 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ± 5%) [C176]
68 VCKYCY1CB104K AB C Capacitor(16WV 0.1µ F) [C177]
69 VCKYCY1CB104K AB C Capacitor(16WV 0.1µ F) [C178]
70 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C182]
71 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C183]
72 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C184]
73 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C185]
74 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C186]
75 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C187]
76 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C188]
77 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C189]
78 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C194]
79 VCKYCY1HB471K AB C Capacitor(50WV 470PF) [C199]
80 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C200]
81 QCNCM2666XH0G AE C Connector(7pin) [CNCIS]
82 QCNCM7014SC0B AD C Connector(2pin) [CNCSW]
83 QCNCM2508SC1B AF C Connector(12pin) [CNLIUA]
84 QCNCM7014SC0F AB C Connector(6pin) [CNMT]
85 QCNCM2666XH1F AF C Connector(16pin) [CNPN]
86 QCNCM7014SC0C AA C Connector(3pin) [CNPRG]
87 QCNCM2638SC0F AE C Connector(6pin) [CNPW]
88 QCNCM2666XH0C AD C Connector(3pin) [CNSP]
89 QCNCM7014SC1E AC C Connector(15pin) [CNTH]
90 VHDHRW0202B-1 AD B Diode(HRW0202B) [D100]
91 VHD1SS355//-1 AB B Diode(1SS355) [D101]
92 VHD1SS355//-1 AB B Diode(1SS355) [D102]
!
93 QFS-L1037YCZZ AD A IC protector(KAB3202) [FU100]
94 VHIF002/TC89B BD N B IC,FLASH ROM(2MB)(Ver.:TC89B) [IC1]
95 RH-IX2321XHZZ AX B IC(IS41LV85125) [IC2]
96 VHISCE209//-1 BH B IC(SCE209) [IC3]
97 VHINJM2113M-1 AG B IC(NJM2113M) [IC4]
98 RH-IX2356XHZZ AL B IC(ULN2001A) [IC5]
99 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ± 5%) [L100]
[6] Control PWB unit
