Sharp UX-P115 User Manual

UX-P115U
10
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
(Unit)
901 DCEKC688TXHZZ BT N E Control PWB unit(Within ROM)
[7] TEL/LIU PWB unit
1 VHVRA391PV6-1 AE B Varistor(RA-391P-V6-2) [AR1]
2 VHVRA501PC6-1 AG B Varistor(RA501P-C6) [AR3]
3 VCEAGA1HW107M AA C Capacitor(50WV 100µ F) [C1]
4 VCEAGA1HW226M AB C Capacitor(50WV 22µ F) [C2]
5 VCEAGA1HW226M AB C Capacitor(50WV 22µ F) [C3]
6 VCEAGA1HW225M AA C Capacitor(50WV 2.2µ F) [C4]
7 VCKYPA1HB103K AA C Capacitor(50WV 0.01µ F) [C5]
8 RC-FZ3024SCZZ AG C Capacitor(250WV 0.82µ F) [C6]
9 VCEAGA1HW475M AA C Capacitor(50WV 4.7µ F) [C7]
10 VCEAGA1HW106M AA C Capacitor(50WV 10µ F) [C8]
11 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C100]
12 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C101]
13 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C103]
14 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C104]
15 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C105]
16 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C106]
17 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C109]
18 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C110]
19 VCCCCY1HH221J AA C Capacitor(50WV 1000PF) [C111]
20 VCKYCY1HB222K AA C Capacitor(50WV 2200PF) [C114]
21 RRLYD3433XHZZ AH B Relay(OUAZ-SH-124DZ) [CML]
22 QCNCW715MAFZZ AF C Connector(12pin) [CNLIUA]
23 VHD1N4148//-1 AA B Diode(1N4148) [D1]
24 VHD1N4148//-1 AA B Diode(1N4148) [D2]
25 VHD1N4148//-1 AA B Diode(1N4148) [D3]
26 VHD1N4148//-1 AA B Diode(1N4148) [D4]
27 RH-IX2383XHZZ AG N B IC(LM2902NS) [IC100]
28 RCILZ2129SCZZ AE C Coil(K5A R6H 6x10(W)2.5TS) [L3]
29 QJAKZ2060SC0B AD C Jack [MJ1]
30 QJAKZ2079XH0D AD C Jack [MJTEL]
31 VHPPC817X4/-1 AC B Photo coupler(PC817X4) [PC1]
!
32 VHPSG206S//-1 AG B Photo transistor(SG206S) [PH1]
!
33 VHPSG206S//-1 AG B Photo transistor(SG206S) [PH2]
34 VSKTC3198GR-1 AD B Transistor(KTC3198GR) [Q1]
35 VSRT1N436C/-1 AD B Transistor(RT1N436C) [Q100]
36 VSRT1P141C+-1 AB B Transistor(RT1P141C) [Q101]
37 VSRT1N436C/-1 AD B Transistor(RT1N436C) [Q102]
38 VSRT1N436C/-1 AD B Transistor(RT1N436C) [Q103]
39 VRS-RE2HA101J AB C Resistor(1/2W 100Ω ± 5%) [R1]
40 VRS-RE3AA122J AC C Resistor(1W 1.2KΩ ± 5%) [R2]
41 VRD-HT2HY202J AA C Resistor(1/2W 2KΩ ± 5%) [R3]
42 VRS-HT3AA510J AA C Resistor(1W 51Ω ± 5%) [R4]
43 VRD-HT2EY101J AA C Resistor(1/4W 100Ω ± 5%) [R5]
44 VRD-HT2EY151J AA C Resistor(1/4W 150Ω ± 5%) [R6]
45 VRD-HT2HY223J AA C Resistor(1/2W 22KΩ ± 5%) [R7]
46 VRD-HT2EY223J AA C Resistor(1/4W 22KΩ ± 5%) [R8]
47 VRS-CY1JB332J AA C Resistor(1/16W 3.3KΩ ± 5%) [R100]
48 VRS-CY1JB621J AA C Resistor(1/16W 620Ω ± 5%) [R101]
49 VRS-CY1JB473J AA C Resistor(1/16W 47KΩ ± 5%) [R102]
50 VRS-CY1JB332J AA C Resistor(1/16W 3.3KΩ ± 5%) [R103]
51 VRS-CY1JB332J AA C Resistor(1/16W 3.3KΩ ± 5%) [R104]
52 VRS-CY1JB273J AA C Resistor(1/16W 27KΩ ± 5%) [R105]
53 VRS-CY1JB823J AD C Resistor(1/16W 82KΩ ± 5%) [R106]
54 VRS-CY1JB362J AA C Resistor(1/16W 3.6KΩ ± 5%) [R107]
55 VRS-CY1JB133J AA C Resistor(1/16W 13KΩ ± 5%) [R108]
56 VRS-CY1JB332J AA C Resistor(1/16W 3.3KΩ ± 5%) [R109]
57 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ± 5%) [R110]
58 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ± 5%) [R111]
59 VRS-CY1JB163J AA C Resistor(1/16W 16KΩ ± 5%) [R112]
60 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ± 5%) [R113]
61 VRS-CY1JB563J AA C Resistor(1/16W 56KΩ ± 5%) [R114]
62 VRS-CY1JB393J AA C Resistor(1/16W 39KΩ ± 5%) [R115]
63 VRS-CY1JB332J AA C Resistor(1/16W 3.3KΩ ± 5%) [R116]
64 VRS-CY1JB822J AA C Resistor(1/16W 8.2KΩ ± 5%) [R117]
65 VRS-CY1JB133J AA C Resistor(1/16W 13KΩ ± 5%) [R118]
66 VRS-CY1JB332J AA C Resistor(1/16W 3.3KΩ ± 5%) [R119]
67 VRS-CY1JB224J AA C Resistor(1/16W 220KΩ ± 5%) [R120]
68 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ± 5%) [R122]
69 VRS-CY1JB152J AA C Resistor(1/16W 1.5KΩ ± 5%) [R123]
70 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ± 5%) [R124]
71 QSW-Z2317XHZZ AF C Hook switch [SW1]
!
72 RTRNI2164XHZZ AG B Transformer(2164) [T1]
73 VHEHZ6A3///-1 AC B Zener diode(HZ6A3) [ZD2]
74 VHEHZ2C1///-1 AA B Zener diode(HZ2C1) [ZD3]
75 VHEHZ2C1///-1 AA B Zener diode(HZ2C1) [ZD4]
76 VHEHZ9C3///-1 AE B Zener diode(HZ9C3) [ZD5]
77 VHEHZ27-1//-1 AB B Zener diode(HZ27) [ZD6]
(Unit)
901 DCEKL477CXH02 BG E TEL/LIU PWB unit
[6] Control PWB unit
