Sharp UX-P115 - [8] Power supply PWB unit (Parts Guide); Power supply PWB unit; [9] Operation panel PWB unit (Parts Guide); Operation panel PWB unit

UX-P115U
11
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[8] Power supply PWB unit
1 0CBUGFM224KR/ AF C Capacitor(275WV 0.22µ F) [C1]
2 0CBUGA0291ZZ/ AC C Capacitor(200WV 220µ F) [C2]
3 0CBUGCU471EL/ AF C Capacitor(1KWV 470PF) [C3]
4 0CBUGXJQF102/ AC C Capacitor(50WV 1000PF) [C4]
5 0CBUGXHWF153/ AF C Capacitor(50WV 0.015µ F) [C5]
6 0CBUEXBAF000/ AC C Resistor(1/16W 0Ω ± 5%) [C6]
7 0CBUGA0315ZZ/ AL C Capacitor(35WV 560µ F) [C8]
8 0CBUGA0302ZZ/ AK C Capacitor(16WV 330µ F) [C10]
9 0CBUGXJXD104/ AD C Capacitor(25WV 0.1µ F) [C12]
10 0CBUGCS222AJ/ AD C Capacitor(500WV 2200PF) [C13]
11 0CBUGXHPF391/ AD C Capacitor(50WV 390PF) [C24]
12 0CBUGCM103BH/ AD C Capacitor(250WV 0.01µ F) [C26]
13 0CBUGCM103BH/ AD C Capacitor(250WV 0.01µ F) [C27]
14 0CBUGCU472BW/ AD C Capacitor(1KWV 4700PF) [C31]
15 0CBPKZ0194ZZ/ AC C Base post ass'y(B 2P3-VH) [CNAC]
16 0CBPCZ0307ZZ/ AD C Connector(IMSA-9110S-06) [CNPS]
17 0CBUBF0002AK/ AD B Diode(10EDB60) [D1]
18 0CBUBF0002AK/ AD B Diode(10EDB60) [D2]
19 0CBUBF0002AK/ AD B Diode(10EDB60) [D3]
20 0CBUBF0002AK/ AD B Diode(10EDB60) [D4]
21 0CBUBA0003BL/ AD B Diode(1S2076A) [D5]
22 0CBUBC0336AZ/ AL B Diode(S3L20U) [D7]
23 0CBUBC0070AM/ AG B Diode(ERA81-004V3) [D8]
24 0CBUBC0169CL/ AE B Diode(ERA22-06V3) [D9]
25 0CBPJCEJ3151/ AH A Fuse(3.15A/AC125V) [F1]
26 0CBPZZ1008ZZ/ AH A Circuit protector(4A/32V) [F3]
27 0CBBFZ89902Z/ AD C Beads core(3A) [FB2]
28 0CBBFZ89633Z/ AD C Beads inductor(BP53RB052025050) [FB3]
29 0CBUKZ1186ZZ/ AH C Filter(33mH/0.5A) [L1]
30 0CBUZZ0213ZZ/ AN C Inductor(RS912) [L2]
31 0CBLRZ6987ZA/ AQ C Heat sink(MN210-5001AT) [MT2]
32 0CBUDC0062MZ/ AG B Photo coupler(PS2501-1L) [PC1]
33 0CBUAG0213AC/ AK B FET(2SK3306) [Q1]
34 0CBUAC0255AM/ AD B Transistor(2SC4115S) [Q2]
35 0CBUAC0264AK/ AD B Transistor(2SC1741AS) [Q3]
36 0CBUAC0034EL/ AD B Transistor(2SC1740S) [Q4]
37 0CBUEXDAW334/ AC C Resistor(1/4W 330KΩ ± 5%) [R1]
38 0CBUEXDAW474/ AC C Resistor(1/4W 470KΩ ± 5%) [R2]
39 0CBUEXDAW474/ AC C Resistor(1/4W 470KΩ ± 5%) [R3]
40 0CBUEEB681CT/ AC C Resistor(1/4W 680Ω ± 5%) [R4]
41 0CBUEXCAP272/ AC C Resistor(1/10W 2.7KΩ ± 5%) [R5]
42 0CBUEXBAF183/ AC C Resistor(1/16W 18KΩ ± 5%) [R6]
43 0CBUEXBAF181/ AC C Resistor(1/16W 18KΩ ± 5%) [R7]
44 0CBUEXBAF473/ AC C Resistor(1/16W 47KΩ ± 5%) [R8]
45 0CBUEXBAF470/ AC C Resistor(1/16W 47Ω ± 5%) [R9]
46 0CBUEFDR15DB/ AE C Metal film resistor(1W 0.15Ω ± 5%) [R10]
47 0CBUEXDAW334/ AC C Resistor(1/4W 330KΩ ± 5%) [R11]
48 0CBUEXDAW334/ AC C Resistor(1/4W 330KΩ ± 5%) [R12]
49 0CBUEEB472CT/ AC C Resistor(1/4W 4.7KΩ ± 5%) [R13]
50 0CBUEXCAP102/ AC C Resistor(1/16W 1KΩ ± 5%) [R14]
51 0CBUEXBAF334/ AC C Resistor(1/16W 330KΩ ± 5%) [R15]
52 0CBUEXBAF103/ AC C Resistor(1/16W 10KΩ ± 5%) [R16]
53 0CBUEXBAF332/ AC C Resistor(1/16W 3.3KΩ ± 5%) [R17]
54 0CBUEEB332CT/ AC C Resistor(1/4W 3.3KΩ ± 5%) [R18]
55 0CBUEEB682CT/ AC C Resistor(1/4W 6.8KΩ ± 5%) [R27]
56 0CBUEEB682CT/ AC C Resistor(1/4W 6.8KΩ ± 5%) [R28]
57 0CBUEEB682CT/ AC C Resistor(1/4W 6.8KΩ ± 5%) [R29]
58 0CBUEFE104DS/ AE C Metal film resistor(2W 100KΩ ± 5%) [R30]
59 0CB829653001/ BF B Transformer(PTTN146-KTT) [T1]
60 0CBUEZ0666ZZ/ AD B Varistor(S07K150GA) [V1]
61 0CBUFBA222EQ/ AD C Variable resistor(2.2KΩ )[VR1]
62 0CBUBDQR270A/ AD B Zener diode(27HSB-26) [ZD1]
63 0CBUBDBE4R3C/ AD B Zener diode(RD4.3SAB) [ZD2]
64 0CBUBDDA300A/ AE B Zener diode(HZ30CPTK) [ZD4]
65 0CBUBDBE6R2C/ AC B Zener diode(RD6.2SAB2-T1) [ZD5]
66 0CBUBDBE100C/ AE B Zener diode(RD10ESAB-T1) [ZD8]
67 0CBUBDBE9R1C/ AD B Zener diode(RD9.1ESAB2-T1) [ZD9]
(Unit)
!
901 RDENT2198XHZZ BG E Power supply PWB unit
[9] Operation panel PWB unit
1 QSW-Q2331XHZZ AE C Tact switch [SW]
!
2 QSW-M2246AXZZ AH C FRSNS sensor
!
3 QSW-M2294XHZZ AE C ORGSNS sensor
(Unit)
901 DCEKP478CXH02 BG E Operation panel PWB unit
