Shelly Wave Pro 1 User Manual

26
14. Technical Specifications
Power supply
110 - 240 V
Power consumption
< 0.3W
Max. switching voltage AC
240 V
Max. switching current AC
16 A
Max. switching voltage DC
N/A
Max. switching current DC
N/A
Overheating protection
Yes
Power measurement
No
Distance
Up to 40 m indoors (131 ft.)
(depends on local condition)
Z-Wave® repeater:
Yes
CPU
Z-Wave® S800
Z-Wave® frequency bands:
868,4 MHz; 865,2 MHz; 869,0
MHz; 921,4 MHz; 908,4 MHz;
916 MHz; 919,8 MHz; 922,5
MHz; 919,7-921,7-923,7 MHz;
868,1 MHz; 920,9 MHz
Maximum radio frequency power transmitted in
frequency band(s)
< 25 mW
Size (H x W x D)
94x19x69 ±0.5 mm / 3.70x0.75x2.71
±0.02 in
Weight
63 g / 2.22 oz.
Mounting
DIN rail
Screw terminals max. torque
0.4 Nm / 3.54 lbin
Conductor cross section
0.5 to 2.5 mm² / 20 to 14 AWG (green
connector)
0.5 to 1.5 mm² / 20 to 16 AWG (white
connectors)
