Sherwood R-607 User Manual

4
Getting Started
Front Panel
8 9 10 11 14 15
1 2 3 4 5 6 7
12 13
1
Main Power Switch
2
Standby Indicator
3
On/Standby Switch
4
IR Sensor
5
Display
6
Surround Select Buttons
7
Master Volume Control
8
Input Selector
9
Headphone Connector
10
F.AUX Input Connector
11
Band Select Button
12
Tuning Up/Down Buttons
13
Preset Select Buttons
14
Stereo Mode Button
15
USB Port
Rear Panel
3 4 5 6 7 8
1 2
1
Digital Audio Connectors
2
HDMI Connectors
3
Tuner Antenna Connectors
4
Analog Audio Connectors
5
Subwoofer Connector
6
Composite Video Connectors
7
Speaker Connectors
8
AC Input Connector

Sherwood R-607 Specifications

General

Brand	Sherwood
Model	R-607
Category	Receiver
Language	English
