20
,, ,
Setting range:
Initial value: OFF
Setting range: OFF, ON
Set whether specified event is enabled or disabled during
standby. For details, refer to Section 5-5 (4).
This screen is displayed when the optional heater break/loop
alarm function is added and used to monitor heater current.
(There is no item to be set on this screen.)
is displayed when stable current value has not been
gained.
NOTE:
Heater break/loop alarm works on output 1.
Heater break/loop alarm is selectable as event 1 or event 2.
Heater break/loop alarm is assignable in case output 1 is of
contact or SSR drive voltage.
1-20
Event at STBY setting screen
To the 1-27 screen
(3) Setting of events
1-27
Heater current monitor screen
Initial value: Hd
Setting range: OFF, Hd, Ld, od, id, HA, LA, So, Hb
The type of event to be selected as event 1 is selected
from the following code table.
1-21
Event 1 type code setting screen
1-22
Event 1 hysteresis setting screen
1-23
Event 1 standby action code setting screen
1-24
1-28
Heater break/loop alarm action setting screen
1-29
Heater break/loop standby action setting screen
1-30
Heater break alarm value setting screen
1-31
Heater loop alarm value setting screen
(4) Setting of Heater break/loop alarm
1-32
Analog output type setting screen
1-33
Analog output scaling lower limit setting screen
(5) Setting of analog output type
To the 1-34 screen
Please refer to section 8-1, 8-2 and 8-3.
Initial value: 5 digit
Setting range: 1 – 999 digit
ON-OFF hysteresis is set for event 1.
This screen is displayed when an alarm type code
is selected from
Initial value: 1
Setting range: 1, 2, 3, 4
An event 1 standby action type code is selected from the
following table.
Table of Event Type (Alarm Type) Codes
Code Type of event Remarks
No selection
Higher limit deviation
Lower limit deviation
Scaleover
Heater break/loop alarm
Initial value of event 1
Initial value of event 2
Standby action is invalid.
Higher limit absolute value
Lower limit absolute value
Initial value: Ld
Setting range: OFF, Hd, Ld, od, id, HA, LA, So, Hb
The type of alarm to be selected as event 2 is selected
from the table of codes.
Initial value: 5 digit
Setting range: 1 – 999 digit
ON-OFF hysteresis is set for event 2.
Initial value: 1
Setting range: 1, 2, 3, 4
An event 2 standby action type code is selected from the
table of 1-23.
Table of Standby Action Codes (1-23, 1-26)
Code Description
1
2
3
4
Without standby function
Standby action when power is applied or when
Standby action when power is applied, when
STBY is switched ON to OFF.
STBY is switched ON to OFF, or when SV in
execution is changed.
Control mode (without standby)
Event 2 type code setting screen
1-25
Event 2 hysteresis setting screen
1-26
Event 2 standby action code setting screen
.deyalpsidsi23-1,detcelestonsinoitpomralakaerbretaehnehW
Initial value:
Setting range: ,
In this mode, once a break or loop alarm is
(Lock mode)
(Real mode)
output, the alarm output is maintained until
OFF is selected on the heater break or loop
alarm value setting screen or the power
supply is cut.
An alarm is turned ON or OFF according to a
rise or fall of the value of current from a set
value. The hysteresis for the release of alarm
output is fixed to 0.2A.
Initial value: OFF
Setting range: OFF, ON
When ON is set, alarm output is withheld or kept to be on
standby until the current value enters its normal range once
even if the current at the time of applying power is such that
an alarm should be output.
Initial value: OFF
Setting range:OFF, 0.1 – 50.0A
Heater current is detected by CT while control output is ON.
Lower current than a set value of current is taken as
abnormal and an alarm is output.
Initial value: OFF
Setting range: OFF, 0.1 – 50.0A
Heater current is detected by CT while control output is OFF.
Higher current than a set value of current is taken as
abnormal and an alarm is output.
Initial value:
An item intended to be output as an analog signal is selected
from 4 items: Measured value (PV), target set value (SV),
control output 1 (OUT1) and control output 2 (OUT2).
Initial value: 0.0 (The lower limit value of setting range for PV
and SV. 0.0 for OUT1 and OUT2.)
Setting range: Within measuring range when PV/SV is
0.0 – 100.0% when OUT1 or OUT2 is selected.
selected.
A minimum value (0mV, 4mA or 0V) of analog output signal is
set as the lower limit value of scaling for an intended output
value.
,,, ,, .
is selected from
,,,,, .
This screen is displayed when an alarm type code
This screen is displayed when an alarm type code
is selected from
,,, ,, .
This screen is displayed when an alarm type code
is selected from
,,, ,, .
.deyalpsidsi53-1,detcelestonsinoitpotuptuogolananehW
Displayed only when
the option is added.
When event option is not selected, 1-27 is displayed.
