Shimaden SRS14A User Manual


(1) Model code check
(SRS11A model code)
SRS11A-8 Y Y-90-P 1 1 1 0
1. Series SRS11A
2. Input 8: Multi-input, thermocouple, R.T.D., voltage (mV) 6: Voltage (V)
3. Control output 1 Y: Contact I: Current P: SSR drive voltage V: Voltage
4. Control output 2 N: None Y: Contact I: Current P: SSR drive voltage V: Voltage
EV3/DI4 E: Event output 1 point (EV3) D: External control input 1 point (DI4)
5. Power supply 90: 100-240V AC 08: 24V AC/DC
6. Programming function N: None P: With (4 patterns, max. 32 steps)
7. Event output 0: None 1: Event output 2 points (EV1, EV2)
8.
Analog output/communication 0: None 3: Voltage (0 ~ 10 mV) 4: Current (4 ~ 20 mA)
6: Voltage (0 ~ 10 V) 5: communication (RS-485)
9. DI/CT input 0: None 1:
CT 2 points input (Can be selected if control output 1 or 2 is Y, P.)
2: External control input 3 points (DI1, DI2, DI3)
10. Remarks 0: None 9: With
(SRS12A/SRS13A/SRS14A model code)
SRS13A-8 Y Y-90-P 1 4 1 2 5 0
1. Series SRS12A, SRS13A or SRS14A
2. Input 8: Multi-input, thermocouple, R.T.D., voltage (mV) 6: Voltage (V)
3. Control output 1 Y: Contact I: Current P: SSR drive voltage V: Voltage
4. Control output 2 N: None Y: Contact I: Current P: SSR drive voltage V: Voltage
EV3/DI4 E: Event output 1 point (EV3) D: External control input 1 point (DI4)
5. Power supply 90: 100-240V AC 08: 24V AC/DC
6. Programming function N: None P: With (4 patterns, max. 32 steps)
7. Event output 0: None 1: Event output 2 points (EV1, EV2)
8. Analog output 0: None 3: Voltage (0 ~ 10 mV) 4: Current (4 ~ 20 mA) 6: Voltage (0 ~ 10 V)
9. CT input 0: None 1:
CT 2 points input (Can be selected if control output 1 or 2 is Y, P.)
10. External control input 0: None 2: Control input 3 points (DI1, DI2, DI3)
11. Communication 0: None 5: Communication (RS-485)
12. Remarks 0: None 9: With
(2) Accessories check
Instruction manual (A3 size paper × 2) 1 copy
Unit seals 1 sheet
Note: In the event you want to inquire about a product defect, missing accessory or other matter, please contact your
nearest Shimaden agent.
2-2. Notes on use
Do not press front panel keys with a hard or pointed object. Press lightly with your fingertips.
To clean, wipe lightly with a dry cloth. Do not use solvents such as thinner.
3. Installation and wiring
3-1. Installation site (environmental conditions)

CAUTION
Environmental conditions for operations
The controller is designed to be used under the following
conditions. Observe the following environmental
conditions when using:

Must be used indoors

Max. elevation: 2000m

Ambient temperature: -10 to 50°C

Ambient humidity: Max. 90%RH, no condensation

Transient over voltage category: II

Pollution class: 2 (IEC 60664)
Do not use the controller in the following locations.
Doing so could lead to equipment failure, damage or fire.
• Places exposed to flammable or corrosive gases, oil mist, or
excessive dust that could cause insulation to deteriorate.
• Places subject to vibration or impact
• Places near strong electric circuit or places subject to inductive interference
• Places exposed to water dripping or direct sunlight
• Places where the controller is struck directly by air from heater or air
conditioner

