Shimadzu LC-40D X3 CL - Component Parts

1.2 Component Parts
This instrument consists of the standard parts listed below. Check the parts against this
list after unpacking.
No. Part Name Part No. Q'ty Remark
-
Main Unit
LC-40D X3 CL/LC-40D XR
CL
- 1
-
Safety Guideline
(Booklet)
*1
228-97195 1
-
Instruction manual/
System Guide (CD-ROM)
228-97193-41 1
- Bottle, 250 mL 228-74372 1
1 Suction Filter Assy 228-45708-91 1 Including a tube
2 REMOTE CABLE ASSY 228-28253-91 1 Not used in CL model.
3 DRAIN TUBE SI(L1000) 228-25162-03 1
4
STOP JOINT ASSY,B,D 228-46054-91 1
SYRINGE TUBE ASSY,B,D 228-46055-91 1
5
SYRINGE,SS-20ESZ 228-66048 1
NEEDLE ASSY,FOR
SYRINGE
228-18216-91 1
6 CLAMP,M9120 046-05522-02 1
7 DRAIN ADAPTER 228-42204 1
8 STANDARD OUT DRAIN 228-42205 1
9 CTO OUT DRAIN 228-42206 1
10 STRAIGHT JOINT 228-28163 1
11 FITTING,L-TYPE 1253 035-61561-12 1
*1
It contains cautions for use regarding the instrument.
2
LC-40D X3 CL LC-40D XR CL
1 Overview
