5.2.3 Maintenance Kit
A set of consumable parts is provided as Maintenance Kit
n Maintenance Kit for LC-40D X3 CL (Parts No. 228-53265-45)
Part Name Part No. Quantity Remarks
PLUNGER SEAL,BACKUP RING UHP 228-52711-93 2 With backup ring
Line Filter ASSY, SUS 228-57501-92 1
Suction Filter ASSY 228-45708-91 1
Plunger Holder ASSY 228-52069-44 2 With diaphragm
Inlet Check Valve ASSY 228-52964-42 2
Outlet Check Valve ASSY 228-53334-96 2
Air Filter for Right Panel 228-53924-06 1
n Maintenance Kit for LC-40D XR CL (Parts No. 228-45593-49)
Part Name Part No. Quantity Remarks
PLUNGER SEAL,BACKUP RING UHP 228-52711-93 2 With backup ring
Line Filter ASSY, SUS 228-35871-96 1
Suction Filter ASSY 228-45708-91 1
Plunger ASSY 228-52069-44 2 With diaphragm
FERRULE 1.6F 316L 228-16000-10 2
MALE NUT 1.6MN 228-16001 2
SUS316LTP 0.3 228-50579-91 1
0.3 mm (I.D.) ´ 2 m
Inlet Check Valve ASSY 228-48249-96 2
Outlet Check Valve ASSY 228-45705-43 2
LC-40D X3 CL LC-40D XR CL
133
5.2 Maintenance Parts
5
