n Selecting the type of external solenoid valve《EXT.SV TYPE》
Not used in CL model.
Do not change the factory default value.
Select the type of flow switching valve
(optional) connected to the [SV] connector
on the back of the instrument.
Set Value Function
0 Do not use FCV.
1 Not used in CL model.
2 Not used in CL model.
n Inputting the serial number of the external flow path switching valve《EXT.SV SERIAL》
Not used in CL model.
Input the serial number of the flow path
switching valve connected to the SV
connector on the back of the instrument.
n Selecting the flow path of the solenoid valve unit《EXT.SV CHANNEL》
Not used in CL model.
LC-40D X3 CL LC-40D XR CL
