56
Settings (EW-EN100)
The setting function can not be used while riding the bicycle.
RD protection reset
In order to protect the system from falls etc., if the bicycle is subjected to a strong impact, the "RD Protection function" is
enabled. The connection between the motor and the link will be momentarily severed so that the rear derailleur can no
longer operate.
Executing "RD Protection Reset" restores the connection between the motor and the link, as well as the function of the rear
derailleur.
1.
Press and hold the button (about 8 second) until the
LED lamps respond as shown in the table on the right.
LED lamp
(outer side)
LED lamp
(inner side)
Button
2.
Rotate the crankarm.
Connection of motor and the link is restored.
RD protection reset.
LED lamp (inner side) LED lamp (outer side)
Blinks red
OFF
Adjust
You can adjust gear shifting only when using an electronic gear shifting unit.
If you need to adjust the derailleur, contact the place of purchase.
Drive unit setting data backup function
The data saved to the drive unit is usually backed up automatically. However, performing the following operations will cause
a message to appear asking whether or not you want to update the backup data.
•
Reinstalling the cycle computer on a bicycle with different settings.
•
Changing the drive unit settings for an E-TUBE PROJECT.
To Next Page
