Dealer’s Manual (SG-C7000-5V / SG-C7000-5R / SG-C7000-5C / SG-C7000-5D)
Return to index page
Click here for the latest Dealer's Manual
NOTICE
• When installing parts such as a mudguard stay to the hub axle, install them in
the order shown in the figure.
Cap nut
Washer
Non-turn washer
Mudguard stay
Carrier stay
• When installing the hub to the frame, the chain guard may come off. Make sure
that the chain guard is securely installed. If not properly installed, noise may be
generated.
LO
CK
7R
Chain guard
