68
Return to index page
Ball retainer
Sun Gear1
guide ring
10. Reverse the axle unit in the vise
to complete assembly.
11. Install the ball retainer.
12. Install the Sun Gear1 guide ring.
NOTICE
•
Be careful, as the balls can easily fall
from the retainer.
•
Keep the vertical direction of the ball
retainer in mind as you set it.
Do this while turning the cassette joint until it
makes contact.
If a shifting lever is connected, do this with the
unit in 1st gear.
(Y-04130100)
(Y-04130100)
(Y-04130100)
Assembling the Internal Assembly
To Next Page
