Switch unit integrated type cycle computer
For model: SC-EN500
It can be installed to Ø22.2 handlebars.
Pass the cycle computer's clamp band around the handlebar.
Insert it from the left side of the handlebar and install it near the handle grip to enable easy operations of
the switch part.
Clamp band
Switch unit integrated type cycle
computer
Handlebar (left side)
The SC-EN500 has a type compatible with I-SPEC EV (SC-EN500-A). Combine the SC-EN500-A and I-
SPEC EV brake lever as indicated in the figure when performing installation.
1.
Installation/removal
Installing the cycle computer
19
