Installing the bracket and cycle computer
Using the installation layout with the cycle computer installed on the front of the handlebar is
recommended for bicycles with drop handlebars.
Check the diameter of the handlebar to determine whether an adapter is needed.
Install the bracket that supports the cycle computer in the position shown in the figure below.
25
3838
25
Handlebar diameter
(Unit: mm)
Bracket installation part
Center of handlebar
Handlebar diameter of stem installation area (mm) Adapter
Ø25.2 - 25.6 Required
Ø31.6 - 32.0 Not necessary
Ø34.8 - 35.2 Not necessary
1.
If adapters are required, push them along to the center of the handlebar.
2.
Installation/removal
Installing the cycle computer
21
