Temporarily install the bracket.
Push the clamp area open, then install the bracket to the center of the handlebar.(1)
Temporarily attach the clamp screw.
Handlebar
Bracket
Adapter
Clamp screw
(Temporary)
(2)
3.
Install the cycle computer to the bracket.
Slide the cycle computer and install it to the bracket.
Be sure to push it in firmly until you feel a click.
4.
Installation/removal
Installing the cycle computer
22
