RB-473-B02M
18
5.4.3. Setting and replacement of printer paper
(1) Push the printer-cover open button to open the cover, and then remove the cover.
Printer-cover open button
(2) Insert the printer shaft into the roll of the paper and set it in the printer unit.
Printer shaft
Printer paper
(3) Hook the tabs of the cover to the tabs of the unit. Take out the end of the paper a little and close the
cover.
Printer cover
Tabs
Printer paper
Use the printer paper exclusive to SLM-5000 only.
Never lose the printer shaft
since it is the part of the printer unit.
To Next Page
