8. F-18 stands for the protection of maximum temperature. Its setting range is
140~250. (If drying temp. exceeds set value, machine halts and alarm
sounds to avoid overheat caused by faults.)
9. F-19 stands for microswitch timeset of honeycomb rotor. “OFF” functions as
shut-off and “ON” functions as open. The setting range is 0~9999 with the
unit is Sec.. (Rotor starts running to monitor time and set time should be less
than that of rotor rotation of one circle. Microswitch can be reset periodically
to monitor if honeycomb runs normally.)
4.10 Wrong Codes Remark
Table 4-1:Wrong Codes Remark
Wrong codes Remark
E-01
Break line of thermocouple
E-02
Power reverse phase, default phase
E-03
Overload of blower
E-04
Drying temp. exceeds EGO set value
E-05
Drying temp. exceeds max. set value
E-07
Overheat protection (PV≥SV plus set value, alarm
sounds)
E-08 Memory errors
E-09
Running fault of honeycomb-rotor
E-10
Regenerative temp. exceeds EGO set value
E-11
Insert errors of thermocouple “+, -”
E-12
PID auto-tuning errors
4.11 Operation of Conveying System
1) Press once to set the suction time of the hopper 1.
Press once to set the suction time of the hopper 2.
Press three times to set the time for opening the valve.
2) Change the required time with key.
3) Press RUN/STOP once, hopper 1 turned on but hopper 2 turned off.
Press RUN/STOP twice, both hopper 1 and 2 turned on.
