Application and Operation
4.2 Machine Startup
1) Pipe connect the inlet and outlet of the standard
water heater to the pipe of mould.
2) Connect the cooling water inlet /backup water
inlet
3) Turn all the ball valves on.
4
.
) Turn on the main power switch.
5) Turn on the pump switch to start the pump.
6) Turn on the heater switch.
7) Set mould temperature (if it is already set, neglect this step.) Press
to set the temperature. For STM W series, maximum
temperature setting value is 120 .
8) Overtemperature setup for system cooling: set as +1 before delivery
which means that whenever actual temperature exceeds setting value
by 1 , cooling system will be automatically activated.
Start
Stop
Actual temperature
Set temperature
4.3 Stop the Machine
1) Switch off heater power.
2) Wait until oil temperature falls below 50 , turn off pump switch.
3) Turn off main switch.
