6.4 Pipe Heater
1) Open machine rear cover door. (Refer to pictures below)
2) Unlock heater cap. (Refer to pictures below)
3) Unlock the screws of pipe heater to take it out. (Refer to the pictures
below.)
4) Install the pipe heater in a reverse order.
