Shinko ACD-13A User Manual

- 10 -
Displays, Indicators
(1) PV indicator
Lights when PV is indicated in PV/SV Display Mode.
(2) PV Display
Indicates the PV or setting characters in setting mode.
(3) SV/MV/TIME indicator
SV: Lights when SV is indicated in PV/SV Display Mode.
MV: Lights when MV is indicated in PV/SV Display Mode.
TIME: Lights when remaining step time (program control) is indicated in PV/SV
Display Mode.
(4) SV/MV/TIME Display
Indicates the SV, MV, remaining step time (program control) or set values in each
setting mode.
(5) MV/DV indicator
MV: Lights when MV is indicated on the bar graph.
DV: Lights when DV is indicated on the bar graph.
(6) MV/DV Bar Graph Display
MV or DV is indicated on the bar graph.
(7) MEMO/STEP indicator
MEMO: Lights when a Set value memory number is indicated.
STEP: Lights when a step number is indicated during program control.
Flashes during Wait action.
(8) MEMO/STEP Display
Indicates the Set value memory number or step number (program control).
(9) M/S indicator
M: Lights when step time unit “Hours:Minutes” is selected in the program control.
S: Lights when step time unit “Minutes:Seconds” is selected in the program control.
(10) Action indicators
OUT1: Lights when control output (OUT1) is ON.
For direct current output type, flashes corresponding to the MV
in 125 ms cycles.
OUT2: Lights when control output OUT2 (D
option) is ON.
For direct current output type, flashes corresponding to the MV
in 125 ms cycles.
EVT1: Lights when Event output EVT1 output occurs.
EVT2: Lights when Event output EVT2 output occurs.
EVT3: Lights when Event output EVT3 output occurs.
EVT4: Lights when Event output EVT4 output occurs.
EVT5: Lights when Event output EVT5 output occurs.
MAN: Lights during manual control.
T/R: Lights during Serial communication (C, C5 option) [TX (transmitting)
output].
AT: Flashes while AT (auto-tuning) or auto-reset is performing.
LOCK: Lights when Set value Lock 1, Lock 2, Lock 3 or Lock 4 is selected.
RUN: Lights while program is running.
HOLD: Flashes while program is on hold (suspended).
