- 11 -
Keys
(11)
UP key: Increases the numeric value.
If this key is pressed for 1 second during program operation (RUN), the unit
proceeds to the next step. (This is the Advance function.)
(12)
DOWN key: Decreases the numeric value.
(13) SET key
Switches setting groups.
Switches step numbers in the Program group.
Switches Set value memory numbers in the ‘SV, Event group’.
Switches block numbers in the PID group.
(14) MODE key
Selects setting modes, and registers the set value (or selection).
(15) RUN/STOP key
For Fixed value control, PV/SV Display Mode or standby mode can be switched
by pressing this key for 1 second.
In standby mode, pressing this key turns all outputs OFF as when the power
supply is turned off.
In program mode, control RUNS/STOPS.
In standby mode, pressing this key RUNS program control.
Program control STOPS by pressing this key for 1 second during program
operation (RUN).
(16) A/M B.MODE key
Switches Auto/Manual control.
If this key is pressed during setting mode, the unit reverts to the previous group
or mode.
Case
(17) Console connector
By connecting to the USB communication cable (CMB-001, sold separately),
the following operations can be conducted from an external computer using
the Console software SWS-AC001M.
• Reading and setting of SV, PID and various set values
• Reading of PV and action status
• Function change
To Next Page
