SHOWTEC 50809 - Product Specifications

19
Order code: 50809
Net-8/3
Product Specifications
Model:
Showtec Net-8/3
Input voltage:
100–240 V AC, 50/60 Hz
Power consumption:
20 W
Fuse:
T1AL/250 V
Dimensions:
483 x 143 x 44,5 mm (LxWxH)
19 inch x 1U (LxH)
Weight:
2,2 kg
Operation and Programming
Signal pin OUT:
pin 1 earth, pin 2 (-), pin 3 (+), pin 4 (N/C), pin 5 (N/C)
Setup:
LCD display for easy setup
Connections:
8 x 3-pin XLR IN/OUT, 2 x RJ45 IN/OUT
Power connection:
Pro power connector Blue IN
Control protocol:
ArtNET, KlingNET, sACN, TCP/IPv4, DMX-512
Electro-mechanical effects
● 8 universes DMX IN/OUT
● Supports Artnet or Klingnet protocol
● Data signal: 1 Gbps data speed
● IP20 rating
Max. ambient temperature t
a
:
From -5 °C to +40 °C
Max. housing temperature t
B
70 °C
Minimum distance:
Minimum distance from flammable surfaces:
0,5 m
Design and product specifications are subject to change without prior notice.
Website: www.Showtec.info
Email: service@highlite.com
