Order code: 50809
Net-8/3
Description of the device
Features
The Showtec Net-8/3 node is a cutting-edge network routing device which converts ArtNET to DMX-512
and DMX-512 to ArtNet. A maximum of 4096 channels can be transmitted over a single CAT5. This makes
the Net-8/3 suitable for small and large-scale events. The NeT-8/3 embeds a built-in network switch to be
used as an ethernet repeater as well as 8 isolated DMX-512 universes which can be used as an input or
output.
● Supports ArtNet and KlingNet protocols
● 1 Gbps data speed
● 8 universes: DMX IN or OUT
● High speed network IN and OUT
● Input voltage: 100–240 V AC, 50/60 Hz
● Power consumption: 20 W
● Connections: 8 x 3-pin XLR IN/OUT, 2 x RJ45 IN/OUT, Pro power connector Blue IN
● Control protocol: ArtNet, KlingNet, sACN, TCP/IPv4, DMX-512
● LCD display for easy setup
● IP rating: IP20
● Operating temperature: From -5 °C to +40 °C
● Fuse: T1AL/250 V
● Dimensions: 483 x 143 x 44,5 mm (LxWxH); 19 inch x 1U (LxH)
● Weight: 2,2 kg
Frontside
Fig. 01
01) Power LED indicator
This indicator will light up when you switch power on.
02) Link LED indicator
This indicator will light up when a network signal is received.
03) Activity LED indicator
This indicator will light up when a DMX signal is received.
04) LCD display
05) Control buttons
