Bytes Content
0-3 IP address, as 32bit unsigned integer in network or
der
4-7 Subnet mask, as 32-bit unsigned integer in network
order
8-13 MAC address, as array of 6 bytes
Note: The Shure device should respond in less than one second on a typical network. If there is no response,
try sending the query again after verifying the destination IP address and port number.
*UDP: User Datagram Protocol
IP Ports and Protocols
Shure Control
Port
TCP/
UDP Protocol Description
Factory De
fault
21 tcp FTP Required for firmware updates (otherwise closed) Closed
22 tcp SSH Not supported Closed
23 tcp Telnet Standard console interface Closed
68 udp DHCP Dynamic Host Configuration Protocol Open
80* tcp HTTP Required to launch embedded web server Open
427 tcp/udp SLP Required for inter-device communication Open
443 tcp HTTPS Not supported Closed
161 tcp SNMP Not supported Closed
162 tcp SNMP Not supported Closed
2202 tcp ASCII Required for 3rd party control strings Open
5353 udp mDNS Required for device discovery Open
5568 udp SDT Required for inter-device communication Open
8023 tcp Telnet Debug console interface Password
8180* tcp HTML Required for web application Open
†
†
†
