Shure PSM1000 User Manual

Shure Incorporated
36/40
Active RF Sensitivity
at 20 dB SINAD
2.2 µV
Image Rejection
>90 dB
Adjacent Channel Rejection
>70 dB
Latency
0.37ms
Squelch Threshold
22 dB SINAD (±3 dB)
default setting
Intermodulation Attenuation
>70 dB
Blocking
>80 dB
Audio Output Power
1 kHz at Less than 1% distortion, Maximum Headphone Output Power, at 16 Ω
100 mW (per output)
Minimum Load Impedance
4 Ω
Output Impedance
<1 Ω
4-band Parametric EQ
Low Shelf Selectable Gain: ±2 dB, ±4 dB, ±6 dB @ 100 Hz
Low Mid
Selectable Gain: ±2 dB, ±4 dB, ±6 dB at 160 Hz, 250 Hz,
400 Hz, 500 Hz, 630 Hz Selectable Q: 0.7, 1.4, 2.9, 5.0, 11.5
High Mid
Selectable Gain: ±2 dB, ±4 dB, ±6 dB at 1 kHz, 1.6 kHz, 2.
5 kHz, 4 kHz, 6.3 kHz Selectable Q: 0.7, 1.4, 2.9, 5.0, 11.5
High Shelf Selectable Gain: ±2 dB, ±4 dB, ±6 dB @ 10 kHz
Volume Limiter
Selectable: OFF (0 dB)to -48 dB in 3 dB steps
Volume Lock
Selectable: 0 dB to -70 dB

Shure PSM1000 Specifications

General

Frequency Range	470–952 MHz (country dependent)
Operating Range	100 m (328 ft) (Typical)
Audio Input	XLR
Network Interface	Ethernet
Receiver Audio Output	XLR, 1/4" (6.3 mm) balanced/unbalanced
Receiver Battery Type	AA
Power Supply	100 to 240 V AC, 50-60 Hz
Weight	Varies by model (refer to specific model documentation)
