Rudder Feedback Unit Wiring
System Operation
Steering Modes
After initially powering on the system the SP120C
will always return to MANUAL mode
If AUTO or GPS mode is active, press
AUTO
once to return.
To control the rudder manually in this mode,
press;
To drive the rudder to PORT
To drive the rudder to STBD
AUTO MODE
To enter AUTO mode, press the button
To change / set the desired course to steer,
press or to increase or decrease
the desired heading value to steer to.
To disengage AUTO mode, press
AUTO
to
return to Manual Mode.
Continued next page
AUTO
TMQ RFU-S
RUDDER
FEEDBACK
UNIT
14m Supplied Cable
RFU 5V
RED
RFU WIPER GRN
RFU av
BLU
5
6 0
0
0
4
CONNECT TO
AP47C
RUDDER
LTW-6PIN
