Note: At the time of shipping, the write protection function is enabled except for address and baud
rate. Once the user completes the register value change, the write protection will be automatically
enabled once again to prevent incidental data loss.
Serial number of the product
Accumulated or totalized flow rate (R)
Set the response time (R/W)
Accumulated/totalized flow rate alarm (R/W)
Upper flow rate limit alarm (R/W)
Lower flow rate limit alarm (R/W)
Offset reset or calibration (W)
Reset accumulated or totalized flow rate (W)
Write protection of selected parameters (W)
The detailed information of each register is described below: Y: enabled; N: disabled
0x0081
Values from 1 to 255 except for 157 (0x9d).
Note: 0 is the broadcast address.
, Serial number
Series Number of the product, SN
SN= value(0x0007), value(0x0008),….,value (0x000C);
Receiving 12 bits as: 2A 47 37 41 45 49 30 32 30 35 38 2A, the corresponding Serial
Number is *G7AEI02058*.
low rate 0x003A ~ 0x003B
Flow rate = [Value (0x003A)*65536 + value (ox003B)]/1000
e.g.
: for a flow rate of 20.340 SLPM, the user will read “0” from register
3A and “20340” from register 0x003B, therefore
Current flow rate = (0*65536+20340)/1000 = 20.340
