www.Siargo.com MF5806E1 User Manual 23 | Page
Accumulated flow rate
0x003C ~ 0x003E
Write
N
Read
Y
Description
Accumulated or totalized flow rate
Value type
UINT 32 + UINT 16
Notes
Accumulated or totalized flow rate
= Value (0x003C) * 65536 + Value (0x003D) + Value (0x003E)/1000
e.g.: for an accumulated flow rate of 3452.245 m
3
, the user will read “0” from
register 0x003C; “3452” from register 0x003D, and “245” from register 0x003E.
Then, the accumulated flow rate = 0 + 3425 + 245/1000=3425.245.
Baud rate
0x0082
Write
Y
Read
Y
Description
Communication baud rate with a PC
Value type
UINT 16
Notes
0 - 4800; 1 - 9600; 2 - 19200; 3 - 38400; 4 - 57600; 5 - 115200.
The default value is 1
, the baud rate is 9600.
For example, when the user reads “2” from register 0x0082, the baud rate is
19200.
Response time
0x008D
Write
Y
Read
Y
Description
Set response time
Value type
UINT 16
Notes
125, 250, 500, 1000, 2000, or 5000, unit is msec.
The default value is
125 msec.
For
example, when the user reads “2000” from register 0x008
D, the response
time is 2000 msec (2 sec)
.
Note: need to disable the write protection.
Alarm: Accumulated
flow rate
0x0096 ~ 0x0097
Write
Y
Read
Y
Description
Alarm set for the maximum value of an accumulated flow rate
Value type
UINT 32
Notes
Alarm values = Value (0x0096)*65536 + Value (0x0097)
When the set value is reached, an alarm will be triggered.
Note: need to disable the write protection.
