3 Product description
This chapter provides information on the special features and properties of the
Absolute Encoder AFS60/AFM60 PROFINET. It describes the construction and the
operating principle of the device.
 Please read this chapter before mounting, installing and commissioning the
device.
3.1 Special features
Properties
Singleturn Encoder
Advanced
Multiturn Encoder
Advanced
Absolute Encoder in 60 mm design


Robust nickel coded disk for harsh environments


High precision and reliability


Large ball bearing spacing of 30 mm


High level of resistance to vibration


Optimal rotational accuracy


Compact design


Face mount flange, servo flange and blind hollow
shaft


18 bit singleturn resolution
(1 to 262,144 steps)


30 bit total resolution
–

12 bit multiturn resolution
(1 to 4,096 revolutions)
–

Round axis functionality
–

PROFINET interface (as per IEC 61784-2)


Supports the encoder profile V4.1 class 3 and 4


Ethernet with Full Duplex, Switched Ethernet,
100 Mbit/s


Supports the Link Layer Discovery Protocol


Supports the diagnostic functions “General
diagnosis history” and “Error counter history”


Supports the function “External Default Setting”


Table 3: Special features of the encoder variants
