SICK AFS/AFM60 PROFINET User Manual

3 PRODUCT DESCRIPTION
32
OPERATING INSTRUCTIONS | AFS60/AFM60 PROFINET 8015078/1EF3/2021-12-13 | SICK STEGMANN
Subject to change without notice
3.5.5 Vendor specific parameters
Index
Subindex
Description
Access
5)
Data type
Data values
1,000
Sensor status (bit oriented)
R
UINT-16
1,001
Sensor status (S_STAT_A, B and C, bit
oriented)
R
Array [0 … 2] UINT-16
.0
Contains the values of sensor status
S_STAT-A
See Table 44 on
page 57
.1
Contains the values of sensor status
S_STAT-B
See Table 45 on
page 58
.2
Contains the values of sensor status
S_STAT-C
See Table 46 on
page 59
1,002
Service log history information, absolute
values
R
Array [0 … 12] UINT-32
.0
Power up counter
1 … n
.1
Operating time in seconds
0 … n
.2
Maximum speed in rpm since the
encoder has been in operation
1 … 9,000
.3
Counter for forward rotation
1 … n
.4
Counter for reverse rotation
1 … n
.5
Counter for direction change
The counter increments if the encoder
changes direction of rotation.
1 … n
.6
Motion time in seconds (is incremented
in case of movement with at least
6 rpm)
0 … n
.7
Current acceleration in rpm/s
0 … n
.8
Maximum internal LED current for the
sensor in µA
0 … FF.FF.FF.FFh
.9
Minimum internal LED current for the
sensor in µA
0 … FF.FF.FF.FFh
.10
Maximum operating voltage in volts
0 … FF.FF.FF.FFh
.11
Maximum operating temperature in °C
0 … FF.FF.FF.FFh
.12
Minimum operating temperature in °C
(must be interpreted as INT-32)
0 … FF.FF.FF.FFh
5
)
R = Read access, W = Write access.
