Subindex .2 – Sensor status (S_STAT-C)
Information:
Encoder in the Synchronous operating mode. The
formation of the position is synchronized with the
process data cycle of the master
Information:
Encoder in the Free Run operating mode. The
formation of the position is not synchronized with
the process data cycle of the master
Preset function has been triggered and accepted
Status information on saving internal diagnostic
data:
Bit 3 = 1 and Bit 2 = 0: Save operation complete
Bit 3 = 0 and Bit 2 = 1: Save operation requested
and operation in progress
Saving the configuration data using the Save
command:
Bit 1 = 1 and Bit 0 = 0: Save operation complete
Bit 1 = 0 and Bit 0 = 1: Save operation requested
and operation in progress
Table 46: Subindex .2 – Sensor status (S_STAT-C)
