Table 2: LEDs
LED Description
PWR Device status display
For measures, see "Troubleshooting", page 81.
■
LED off: No operation
■
LED green: Interference-free operation
■
LED flashes orange: Warning
■
LED flashes red: Error
MF1/2 The status (output level) of the MF1 multifunctional input/output and MF2
multifunctional output
MF1 MF2
LED off LOW LOW
Blue LED HIGH LOW
Yellow LED LOW HIGH
LED, white HIGH HIGH
LNK1/LNK2 Connection status (link) Ethernet port 1 and port 2
■
LED flashes orange: Data exchange active
■
LED green: Connection (link) to the next participant available.
■
LED off: No physical connection to the next participant available. For
measures, see "Ethernet problems", page 83.
BF/SF The status of the PROFINET interface is indicated by two LEDs.
BF SF Description
Off Off
•
Device is in the
initialization phase
(approx 1.5 s).
•
PROFINET connec‐
tion OK
Flashing red Off
•
Ethernet connection
OK
•
PROFINET connec‐
tion is being estab‐
lished.
•
Device not config‐
ured or incorrectly
configured see "Gen‐
eral faults, warn‐
ings, and errors",
page 81.
Red Off No Ethernet connection
see "General faults,
warnings, and errors",
page 81.
Off or flashes red Flashing red PROFINET user flashing
test active.
3.4.2 Display
The device has a display which provides a range of information. You can also call up
and set parameters using the display.
Symbols for operating modes
The device has two different operating modes, “measured value display” and “menu
display”, which are indicated on the display by the symbols RUN and MEN.
