Rel. Adr. Description
12 Current speed in the selected resolution taking into account the direction
of measurement.
Type
•
Signed 32-bit number in two´s complement
Module parameters
Name Description
Distance Resolution Select the resolution for the distance output value via the digital data
interface. The output value corresponds to the measured value [mm]
divided by the selected resolution. The parameter does not have any
influence on the measured value shown on the display.
Options
•
0.1 mm
•
0.125 mm
•
1 mm
•
10 mm
•
100 mm
•
free Distance Resolution
Factory setting
•
0.1 mm
free Distance Resolu‐
tion [μm]
Determines the resolution of the distance value if the free Distance Resolu‐
tion value has been selected in the Distance Resolution parameter.
Options
•
1 ... 100,000 [μm]
Factory setting
•
100 [μm]
Speed Resolution Select the resolution in mm/s for the speed output value via the digital
data interface. The output value corresponds to the measured value
[mm/s] divided by the selected resolution. The parameter does not have
any influence on the measured value shown on the display.
Options
•
0.1 mm/s
•
1 mm/s
•
10 mm/s
•
100 mm/s
•
free Speed Resolution
Factory setting
•
1 mm/s
free Speed Resolution
[µm/s]
Determines the resolution of the speed value if the free Speed Resolution
value has been selected in the Speed Resolution parameter.
Options
•
1 ... 100,000 [µm/s]
Factory setting
•
1,000 [µm/s]
10.3.8 Module 10: Status/i2b, Control/o2b
Type
Input and output module, 2 bytes
10 PROFINET IO INTERFACE
66
