Module parameters
Name Description
Distance Resolution Select the resolution for the distance output value via the digital data
interface. The output value corresponds to the measured value [mm]
divided by the selected resolution. The parameter does not have any
influence on the measured value shown on the display.
Options
•
0.1 mm
•
0.125 mm
•
1 mm
•
10 mm
•
100 mm
•
free Distance Resolution
Factory setting
•
0.1 mm
free Distance Resolu‐
tion [μm]
Determines the resolution of the distance value if the free Distance Resolu‐
tion value has been selected in the Distance Resolution parameter.
Options
•
1 ... 100,000 [μm]
Factory setting
•
100 [μm]
Speed Resolution Select the resolution in mm/s for the speed output value via the digital
data interface. The output value corresponds to the measured value
[mm/s] divided by the selected resolution. The parameter does not have
any influence on the measured value shown on the display.
Options
•
0.1 mm/s
•
1 mm/s
•
10 mm/s
•
100 mm/s
•
free Speed Resolution
Factory setting
•
1 mm/s
free Speed Resolution
[µm/s]
Determines the resolution of the speed value if the free Speed Resolution
value has been selected in the Speed Resolution parameter.
Options
•
1 ... 100,000 [µm/s]
Factory setting
•
1,000 [µm/s]
10.3.5 Module 5: Distance/i2w, Preset Dyn./o2w
Type
Input and output module, 2 words, consistent
Description
This module reads the current distance value. When writing the module, the reference
value (preset value) defined in it is transferred to the device. The time the reference
value is applied in the device is determined by setting the most significant bit (0->1
edge change bit 31). The distance value measured at this time is automatically
provided with an offset and therefore adjusted to the reference value. The following
applies: Offset = Preset – measured distance value. Setting bit 30 (0→1 edge change)
resets the reference value and offset to 0 mm.
10 PROFINET IO INTERFACE
62
O P E R A T I N G I N S T R U C T I O N S | DL100 Pro PROFINET HighFeature 8021823/19HC/2021-10-15 | SICK
