Rel. Adr. Description
1 Signal attenuation [dB] see "Received signal level", page 28.
Type
•
Signed 16-bit number in two´s complement
3 Operating hours in units of 10 hours.
Type
•
Signed 16-bit number in two´s complement
10.3.10 Module 20: Setup MFx
Type
Configuration module, no input and output data
Description
This module defines the behavior of the switchable MF1 input and output.
Table 29: Module parameters for Setup MFx
Name Description
MFx Activate or deactivate MF1 and MF2.
Options
•
enable
•
Disable
Factory setting
•
enable
Table 30: MF1 module parameter
Name Description
Function MF1 Select function for MF1 input and output.
Options
•
[Output] Distance Threshold: Output is switched when the distance has
been overwritten from the module parameter [MF1 Distance] threshold.
•
[Output] Speed Threshold: Output switches when the speed limit from
the [MF1 Speed] Threshold module parameter has been exceeded. The
direction is set in the [MF1 Speed] Mode module parameter.
•
[Output] Service: The output switches if at least one of the service bits
selected under [MF1 Service] Laser Warning...[MF1 Service] Heating has
been set.
•
[Input] Laser Off: Measurement laser is deactivated via the input.
•
[Input] Preset Static: "Preset Static” function activated via the input.
Factory setting
•
[Output] Distance Threshold
[MF1] Active State Select active level or signal edge of MF1
Options
•
low
•
High
Factory setting
•
low
[MF1 Distance] Thresh‐
old [mm]
Enter the distance threshold value.
Options
•
-300,000 ... 300,000 [mm]
Factory setting
•
1,990 [mm]
