SICK DL100 Pro PROFINET HighFeature - Module 13: Temp;I1 B, Level;I2 B, Hrs;I2 B

Rel. Adr. Description
1.1 Bit = 1: Device-internal heating in operation
Type
•
1 bit
1.2 Bit = 1: Either a input level is active at MF1 of the output is active.
Type
•
1 bit
1.3 Bit = 1: MF2 output is active.
Type
•
1 bit
1.4 ... 1.6 Reserved
Type
•
1 bit
1.7
•
Bit = 0: Device ready for operation
•
Bit = 1: Device not ready for operation. Possible causes could be
hardware errors, temperature errors, optical or electrical interference
or a deactivated laser diode.
Type
•
1 bit
Output values
Rel. Adr. Description
0.0 ... 0.7 Reserved
Type
•
1 bit
1.0
•
Bit = 1: Switch off laser
•
Bit = 0: Switch on laser
Type
•
1 bit
1.1 ... 1.7 Reserved
Type
•
1 bit
10.3.9 Module 13: Temp/i1b, Level/i2b, Hrs/i2b
Type
Input module, 5 bytes, consistent
Description
The diagnostic data of the device can be read using this module.
Input values
Rel. Adr. Description
0 Device temperature [°C]
Type
•
Signed 8-bit number in two´s complement
10 PROFINET IO INTERFACE
68
