Description
This module reads the device status bytes and writes the control bytes into the device.
An active bit (bit = 1) in the status bytes means that the event listed in the associated
description is present. For possible causes and how to troubleshoot warnings or errors
see "General faults, warnings, and errors", page 81.
Input values
Rel. Adr. Description
0.0 Bit = 1: Plausibility warning
Measured values are faulty. Extrapolated measured values are output
instead see table 21, page 44, ErrRej. This may be caused by an internal
error, hardware errors, obstruction of the light beam, optical interference
or electrical interference. The likelihood of an error occurring is high.
Type
•
1 bit
0.1 Bit = 1: Temperature warning
Internal temperature of the device has reached the critical value. The
likelihood of an error occurring is high.
Type
•
1 bit
0.2 Bit = 1: Signal level warning
The signal attenuation has reached the critical value, e.g., due to contam‐
ination. The likelihood of an error occurring is high.
Type
•
1 bit
0.3 Bit = 1: Laser warning
The device must be replaced soon due to aging of the laser diode. The
likelihood of an error occurring is high.
Type
•
1 bit
0.4 Bit = 1: Plausibility error
No valid measured value can be calculated.
Type
•
1 bit
0.5 Bit = 1: Temperature error
The device is operating outside the specified temperature range.
Type
•
1 bit
0.6 Bit = 1: Signal level error
The signal attenuation is too high.
Type
•
1 bit
0.7 Bit = 1: Laser error
Laser error – the laser diode may have reached the end of its service life
see "Module 13: Temp/i1b, Level/i2b, Hrs/i2b", page 68.
Type
•
1 bit
1.0 Bit = 1: Laser switched off
Type
•
1 bit
