Name Description
[MF2 Service] Not
Ready
The output switches when the device is not ready for operation. Possible
causes could be hardware errors, optical or electrical interference or
a deactivated laser diode. This warning message is also issued during
initialization.
Options
•
off
•
on
Factory setting
•
on
[MF2 Service] Heating
Status
The output switches if the internal device heater is in operation.
Options
•
off
•
on
Factory setting
•
on
10.3.11 Module 22: Setup Preset Static
Type
Configuration module, no input and output data
Description
This module is used to set the reference value for the static preset via digital input MF1
see "MF1 – Preset submenu", page 42.
NOTE
If module 5 Distance/i2w, Preset Dyn./o2w is also loaded, the static preset value is
overwritten by the dynamic preset value from the input data of module 5.
Module parameters
Name Description
Distance Preset Static
[mm]
Define the distance preset value.
Options
•
-300,000 ... 300,000 [mm]
Factory setting
•
0 [mm]
10.3.12 Module 23: Setup Offset
Type
Configuration module, no input and output data
Description
This module is used to set the offset.
NOTE
If a preset is triggered via module 5 Distance/i2w, Preset Dyn./o2w or digital input MF1,
the offset value specified via module 23 is overwritten by the offset value calculated
during the preset.
PROFINET IO INTERFACE 10
