S
et
E
s
c
<
<
ca. 1° … 3°
1
2
3
4
5
Figure 6: Reflector tilt for shiny surfaces and horizontal driving axis
1
Device
2
Shiny surface suchas a shelving section, stretch wrap
3
Reflector
4
Tilt of approx. 1° to 3°
5
Shiny surface suchas a rail
5 MOUNTING
