APPENDIX 7
7 Appendix
7.1 Conformities
7.1.1 CE certificate
The Flow-X flow computer has been developed, manufactured and tested according to the
following EU Directives:
● EMC Directive 2004/108/EG (until 19 April 2016), 2014/30/EU (as from 20 April
2016)
● Measuring Instrument Directive 2004/22/EG (until 19 April2016), 2014/32/EU (as
from 20 April 2016)
The conformity with the above Directives has been determined and the CE label attached to
the device.
7.1.2 Standards compatibility and type approvals
The Flow-X flow computer conforms to the following standards or recommendations:
● EN 61000-6-4
● EN12405-1, A2
● AGA 10
● AGA 8
Type approval for commercial or custody transfer has been granted by the relevant
authorities, e.g.:
● MID approval, NMI (Nederlands Meetinstituut): T10548 (Flow-X/P, X/M, X/S, X/R)
T11449 (Flow-X/C)
7.2 General specifications
Item Type Description Quantity
Temperature
Operating
hours
Operating temperature
range
Flow-X/S: 5 ... 55 °C (41 ... 131 °F)
Flow-X/P: -25 ... 55 °C (-13 ... 131 °F)
Flow-X/C: -25 ... 55 °C (-13 ... 131 °F)
Temperature Storage Storage temperature range
Flow-X/S: -40 ... 75 °C (-40 ... 167 °F)
Flow-X/P: -25 ... 70 °C (-13 ... 158 °F)
Flow-X/C: -25 ... 70 °C (-13 ... 158 °F)
Processor Freescale
i.MX processor with math
coprocessor and FPGA
400 MHz
Memory RAM Program memory 2 GB
Flash FRAM
Permanent storage / data
recording storage
1 GB
Data
memory
MMC Memory for data recording 1024 MB
Clock RTC
Real time clock with
internal lithium cell,
accuracy better than 1 s/
day
Table 11: General specifications
