Table 4: Status display of the microSD memory card
Display LED Color Status
MicroSD Lights up Green The device writes data to the correctly installed memory
card.
Read access to the card is not signaled.
3.3.3 Acoustic status indicator
The beeper (buzzer) is located under the cover on the top of the device, see "Device
view", page 14. The API contains functionality for setting the beep duration, the pitch,
the tone sequence and the volume level.
3.3.4 Memory card
The device has a card slot integrated in the housing. The card slot accommodates a
memory card in microSD format.
NOTE
The microSD memory card is optional and not included in the scope of delivery of the
device. The device supports memory cards up to max. 32 GB.
Only use types (industrial standard) approved by SICK to ensure reliable function of the
memory card. You can find these as accessories online at:
•
www.sick.com/InspectorP62x
The memory card has no write protection that can be activated.
Inserting the memory card in the device:
DANGER
Risk of injury due to hot device surface.
The surface of the device can become hot during operation.
•
Before performing work on the device (e.g. mounting, cleaning, disassembly),
switch off the device and allow it to cool down.
•
Ensure good lost heat transfer from the device.
NOTICE
Risk of damage to the memory card!
b
To avoid damaging the microSD memory card, make sure the device is de-ener‐
gized when you insert or remove the card. For this purpose, disconnect the device
from the supply voltage.
Access to the card slot
The card slot for the memory card is located under the hinged cover on the rear side of
the device.
1. 3.
LNK TX
Userdefined
100
70
40
0
[mm]
[%]
LNK TX
Userdefined
100
70
40
0
[mm]
[%]
2.
PRODUCT DESCRIPTION 3
8024439/1EJ6/2022-02 | SICK O P E R A T I N G I N S T R U C T I O N S | InspectorP62x
17
Subject to change without notice
