11 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/InspectorP62x
Please note: This documentation may contain further technical data.
11.1
Features
Type Value
Task Quality inspection
Position determination
Measuring, 2D
Code reading
1
Technology 2D snapshot, image analysis
Shutter technology Global shutter
Product category Programmable, configurable
Pre-installed SensorApp Quality Inspection, based on SensorApp framework SICK Nova
that enables functional extensions via tool plug-ins and custom
development
Toolkit HALCON
Sensor CMOS matrix sensor, grayscale values
Focus Adjustable focus (electric)
2
Working distance 300 mm ... 1.500 mm
3
Integrated illumination
unit
4 LEDs (2 on the left, 2 on the right)
Light color combination, type-dependent, identifier see "Type
code", page 13:
•
Visible blue light (λ = 470 nm ± 15 nm)
•
Visible red light (λ = 617 nm ± 15 nm)
•
Invisible infrared light (λ = 850 nm ± 25 nm)
Feedback LED (spot in field
of view)
1 LED:
Visible green light (λ = 525 nm ± 15 nm)
Laser alignment aid (2
points in the field of view)
2 LEDs, can be deactivated:
Visible red light (λ = 630 nm ... 680 nm)
Light source Illumination LEDs: visible red light (λ = 617 ± 15 nm), visible blue
light (λ = 470 ± 15 nm)
Feedback spot: visible green light (λ = 525 ± 15 nm)
Aiming laser: visible red light (λ = 630 ... 680 nm)
LED class Risk group 1 (IEC 62471:2006-07, EN 62471:2008-09)
Laser class Class 1 Laser Product, according to EN/IEC 60825-1:2014. Com‐
plies with 21 CFR 1040.10/11 except for conformance with IEC
60825-1 Ed.3., as described in Laser Notice No.56, dated May 8,
2019.
Spectral range Approx. 400 nm ... 900 nm
11 TECHNICAL DATA
46
O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 8024439/1EJ6/2022-02 | SICK
Subject to change without notice
