Type Value
Lens Integrated
1
Not yet available in pre-installed Quality Inspection SensorApp.
2
The focusing engine allows an app to control the image focus distance in an auto-focus manner. The
focusing engine should only be used for teach-style or batch change autofocus, and not as part of a
frequent measurement cycle.
3
For details, see "Field of view diagrams", page 22.
11.2 Mechanics and electronics
Type Value
Electrical connection 1 x M12, 17-pin male connector (serial, I/Os, voltage supply)
1 x M12, 4-pin female connector (Ethernet)
Supply voltage DC 12 V ... 24 V, ± 20%
Voltage source as per ES1 and PS2 or lower (EN62368-1), or as
per SELV (EN60950-1)
Power consumption Typ. 4 W
Enclosure rating IP65
Weight 170 g
Housing material Aluminum die cast
Window material Glass
11.3 Performance
Type Value
Image sensor resolution see "Type code", page 13
Scan/frame rate 50 Hz
11.4 Interfaces
Type Value
Serial
1
RS-232, RS-422
Data transmission rate: 300 Baud ... 115.2 kBaud
Ethernet TCP/IP
Function: FTP
1
, HTTP
Data transmission rate: 10/100 MBit/s
CAN
1
Function: SICK CAN sensor network (master/slave)
EtherNet/IP Data transmission rate: 10/100 MBit/s
EtherCAT®
1
Type of fieldbus integration: Optional over external fieldbus mod‐
ule CDF600
PROFINET Built-in, additionally available (optional) via external fieldbus mod‐
ule CDF600-2200
PROFIBUS DP
1
Type of fieldbus integration: Optional over external fieldbus mod‐
ule CDF600-2
Operator interfaces Web server
Configuration software Web GUI (SensorApp configuration), SICK AppStudio (program‐
ming)
Data storage and retrieval Image and data logging via microSD memory card
Image and data logging via external FTP
1
Output current ≤ 100 mA
TECHNICAL DATA 11
8024439/1EJ6/2022-02 | SICK O P E R A T I N G I N S T R U C T I O N S | InspectorP62x
47
Subject to change without notice
