Position Description
12 Focal length
B: 9.6 mm
F: 17, 1 mm
G: 17, 1 mm with visible block
filter
13 Connectivity package
B: Ethernet, serial, CAN, I/O,
USB, memory card slot
14 IP Protection class
5: IP 65
1)
Front view
2)
IR = Infrared light
NOTE
Not all combinations are possible according to the type code. The available device
variants can be found online at:
•
www.sick.com/InspectorP62x
3.3 Product characteristics
3.3.1 Device view
NOTICE
Damage to the swivel connector from over-rotation
•
The swivel connector may be moved up to a maximum of 180° from end point to
end point. Do not exceed the respective limit position.
•
Carry out the rotational movement slowly.
8
6
4
Ready
Read Diagn
Result
TeachIn
LED
Auto-Setup
Data
Autofocus
LNK TX
Userdefined
300
200
100
70
40
100
0
[mm]
[%]
2
3
a
ß
7
9
35.6 (1.40)
6 (0.24)
10 (0.39)
5
1
26.5
(1.04)
71 (2.80)
17.44
(0.69)
4.8 (0.19)
21.5
(0.85)
26
(1.02)
43 (1.69)
Ø 10
(0.39)
1
â
á
ã
à
Figure 2: Structure and dimensions, unit: mm (inch), decimal separator: period
1
4 threaded mounting holes, M5: blind tapped hole; 5 mm deep; max. depth of thread
5 mm
3 PRODUCT DESCRIPTION
14
O P E R A T I N G I N S T R U C T I O N S | InspectorP62x 8024439/1EJ6/2022-02 | SICK
Subject to change without notice
