Table 10: Protection of the supply voltage in the connection module
Connection modules Supply voltage fuse protec‐
tion
Reference
CDB650-204 2 A (slow-blow) see "Connecting supply voltage
for the device in CDB650-204",
page 54
CDM420-0006 2 A (slow-blow) see "Connecting supply voltage
for the device in CDM420-0006",
page 62
6.6.3 Wiring the data interface
Wiring the Internet interface
1. Connect the device to the Ethernet connection of the computer via the adapter
cable.
2. Set up communication via the SICK AppManager software.
NOTE
The Ethernet interface of the device has an Auto-MDIX function. This automatically
adjusts the transmission speed as well as any necessary crossover connections.
Wiring the serial data interface
The maximum data transmission rate for the serial interface depends on the length of
cable and on the type of interface.
Table 11: Data transmission rates and recommended maximum lengths of cable
Interface Data transmission rate Distance to the target computer
(host)
NOTICE
Risk of damage to the internal interface modules!
If the serial data interfaces are wired incorrectly, then electronic components in the
device could get damaged.
■
Observe the information on wiring.
■
Carefully check the wiring prior to switching on the device.
NOTE
Control the serial data interface in the device with the API functions. In order to activate
the serial data interface, use an installed SensorApp which contains this function.
Wiring data interfaces via a connection module
Connection modules Data interface Reference
6.6.4 Wiring the CAN interface
NOTE
Control the CAN data interface in the device with the API functions. In order to activate
the CAN data interface, use an installed SensorApp which contains this function.
