Pin Signal Function Wire color
16 N. c. – Yellow-brown
17 N. c. – White-gray
13.2.2 “Power/SerialData/CAN/I/O” connection to customer-specific connection equipment or control
cabinet
Adapter cable suitable for drag chain, deep-freeze compatible
Part no. 2075220 (5 m), shielded, suitable for drag chain, deep-freeze compatible,
suitable for 2 A
Permitted currents for ambient temperature +40 °C:
•
Contact 1 (blue) and contact 2 (brown): 2 A
•
All other contacts: 1.5 A
Ambient temperature range:
For mobile installation: –25 °C to +80 °C, for fixed installation: –40 °C to +85 °C
...
ð
3
1
7
2
6
5
4
8
13
14
17
15
9
10
12
16
11
1 2
Figure 22: Adapter cable, part no. 2075220 (5 m)
1
Female connector, M12, 17-pin, A-coded (view from front)
2
Illustration may differ
13.2.3 Host interface RS-232 via CDB/CDM connection module to host (PC)
Adapter cable
Part no. 2020319 (3 m), unshielded
Ambient temperature range:
For mobile installation: –5 °C to +90 °C, for fixed installation: –30 °C to +90 °C
Figure 23: Adapter cable, part no. 2020319 (3 m)
1
Female connector, D-Sub, 9-pin (view from front)
2
Illustration may differ
Table 15: Signal assignment of adapter cable with open end
Pin Signal at PC Function Wire color
1 – – –
2 RxD (RS-232), host Host interface (receiver) Brown
1)
3 TxD (RS-232), host Host interface (sender) Blue
2)
ANNEX 13
8024439/1EJ6/2022-02 | SICK O P E R A T I N G I N S T R U C T I O N S | InspectorP62x
51
Subject to change without notice
