Features
Actuating frequency ≤ 100 Hz
1)
Specified values apply to steel (FE360). A correction factor must be used for other materials see
table 3.
Table 13: Correction factor for sensing ranges S
ao
, S
ar
and S
n
Material Correction factor
Mu-metal 1.2
Molded metal 1.1
Structural steel (Fe 360) 1.0
Rust-free steel (V2A, 304) 0.8
Aluminum 0.45
Copper 0.3
Brass 0.4
Table 14: Interfaces
Interfaces
System connection (voltage supply and local outputs)
IME2S12 Cable with M12 male connector, 4-pin
M12 male connec
tor, 4-pin
Open cable
IME2S18 M12 male connector, 4-pin
IME2S30 M12 male connector, 4-pin
IQB2S12 Cable with plug, M12, 4-pin
M8 male connec
tor, 4-pin
Open cable
Table 15: Electrical data
Electrical data
Protection class III (EN 61140/IEC 61140)
Supply voltage V
S
DC 24 V (19.2 V DC … 28.8 V DC)
Residual ripple ±10%
1)
Rated insulation voltage U
i
28.8 V
Voltage drop (of supply voltage) ≤ 3 V
2)
Contamination degree 3 (external, according to EN 60947-1)
Rated impulse withstand voltage U
im
p
1,500 V
Utilization category (IEC 60947-5-1) DC-12: 24 V / 20 mA
Device fuse 1 A
Current consumption at 24 V < 20 mA
Hysteresis ≤ 15% of S
n
Repeatability 2%
Power-up delay (after supply voltage applied)
3)
< 1 s
Response time (removal from response range) < 1 ms
Release time (response time when approaching response range)
IME2S12 < 1 ms
IME2S18-05B4DC0 < 2 ms
IME2S18-08N4DC0 < 1 ms
11 TECHNICAL DATA
26
O P E R A T I N G I N S T R U C T I O N S | IME2S, IQB2S 8023341/17AZ/2020-03-24 | SICK
Subject to change without notice
