Electrical data
IME2S18-08B4DC0 < 1.5 ms
IME2S30-12B4DC0 < 5 ms
IME2S30-15N4DC0 < 1 ms
IQB2S < 2 ms
Risk time
4)
< 20 ms
1)
Within the limits of U
V
.
2)
AT 50 mA at each OSSD channel
3)
Once the supply voltage has been switched on, the OSSDs are in the OFF state during the time delay
be
fore availability.
4)
The risk time is the time needed to detect internal and external faults. External errors affect the OSSDs
(short-circuit to an OSSD and cross-circuit between the two OSSDs). At least one of the two OSSDs is
safely switched off during the risk time.
Table 16: Mechanical data
Dimensions see "Dimensional drawings", page 29
Material IME2S
Housing Nickel plated brass
Sensor surface Vistal
®
Cable PVC
Fixing nuts Brass alloy
Material IQBS
Housing Vistal
®
Sensor surface Vistal
®
Cable PVC
Tightening torque for mounting
IME2S 12 Nm
IQB2S 1 Nm
Weight see "Table of weights", page 28
Table 17: Outputs
Outputs
Switching outputs 2 PNP semiconductors
Switching voltage
ON state 19.2 V DC … 28.8 V DC
OFF state 0 V DC … 2 V DC
Switching current
ON state ≤ 50 mA
OFF state < 500 µA
Load capacity 80 nF
Short-circuit protection Yes
Reverse polarity protection Yes
Test pulse width 300 µs
Table 18: Ambient data
Ambient data
Enclosure rating IP 67 (IEC 60529)
1)
TECHNICAL DATA 11
8023341/17AZ/2020-03-24 | SICK O P E R A T I N G I N S T R U C T I O N S | IME2S, IQB2S
27
Subject to change without notice
