IQB2S
L = 2000 ±30
12
M3 (2 x)
26
17,75
3,2
3,2
5,5
4,25
16
32
4
10
40
Figure 24: IQB2S12-**B**W2 dimensional drawing
12
M3 (2 x)
26
17,75
3,2
3,2
5,5
4,25
46,5
16
32
4
10
40
Figure 25: IQB2S12-**B**TO dimensional drawing
11 T
ECHNICAL DATA
32
